Johnson Pump Macerator Pump 12V – 10-24453-01

Description:

Johnson PumpMacerator Pump TA3P10-19, 12vModel:10-24453-01The Johnson Pump brand TA3P10-19 Macerator pump takes care of the toilet/livewell waste, shredding it before it is pumped into or out from the holding tank. The pump should be connected as close as possible to the holding tank discharge outlet or the bowl discharge outlet. Note! Use unbleached lavatory paper only.Features:Ignition protected motor, conforming with ISO 8846 MarineMounting bracket for easy replacementExtremely energy efficientRotary cutter casing of PET (thermoplastic polyester)Directly connected to sewage line or holding tankCapacity at 0.2 bar (6.7 ft):37 l/min - 10 GPMInlet Connection:11/2" (dia 38 mm) hose or 11/2"NPTAmperage: 15 AFuse Size: 20 AOutlet Connection: 1" (25.4 mm) hoseMotor: 12V DC (with built-in thermal protection)Pump Body: Phenol Plastic (PF)Impeller: NitrileCutter Casing: Thermoplastic Polyester (PET)Shaft: Stainless SteelSeal: Lip SealLength: 230 mm - 9.06"Width: 108 mm - 4.25"Height: 82 mm - 3.23"Weight: 1.9 kg - 4.2 lbs.CE-Approved Manufacturer : Johnson Pump Manufacturer Part No : 10-24453-01 UPC : 787766709018
